eye tribe output and opensesame

Comments

• sebastiaan

  October 2016

  Hi Andrea,

  Good to see you on the forum! This is probably a common situation, so here's a script that does essentially what you want:

  • It reduces the data from a format where every row corresponds to a sample to a format where every row corresponds to a fixation
  • It also checks for each fixation whether it matches one of the ROIs that's specified at the top of the file, and, if so, labels it.

  This script uses DataMatrix, which is a simplified way to work with this kinds of tabular data. (I designed it essentially for OpenSesame and my own analyses.) The basic usage is explained in this notebook:

  • https://github.com/smathot/python-datamatrix/blob/master/using-datamatrix.ipynb

  DataMatrix is not a default part of Python, but you can install through pip install python-datamatrix.

  Cheers!
  Sebastiaan

  from datamatrix import io, DataMatrix
  from datamatrix import operations as ops

  INPUTFILE = 'test.tsv'
  OUTPUTFILE = 'summary.csv'
  ROIS = {
      'ROI-A' : {
              'x1' : 400,
              'y1' : 400,
              'x2' : 800,
              'y2' : 800
          },
      'ROI-B' : {
              'x1' : -800,
              'y1' : 200,
              'x2' : -400,
              'y2' : 400
          },
      }

  # Read in the data
  dm = io.readtxt(INPUTFILE, delimiter='\t')
  # Create a new column, fixnr, that labels each sample with
  # a fixation number, or -1 if it's not part of a fixation
  dm.fixnr = -1
  # Now loop through all samples, and start labeling the fixations
  fixnr = -1
  for rownr, row in enumerate(dm):
      # Ignore whatever is not a fixation
      if row.fix == 'FALSE':
          continue
      # Increase the fixation number if we encounter a new fixation
      if rownr == 0 or dm[rownr-1].fix == 'FALSE':
          fixnr += 1
      # Label the sample as belonging to a fixation
      row.fixnr = fixnr
  # Remove everything that's not a fixation
  dm = dm.fix == 'TRUE'
  # Create a new datamatrix that we're going to use for the summary data.
  # That is, we're going to reduce the data from samples to fixations.
  summarydm = DataMatrix(length=fixnr)
  summarydm.stime = -1
  summarydm.dur = -1
  summarydm.x = -1
  summarydm.y = -1
  summarydm.psize = -1
  summarydm.fixnr = -1
  summarydm.roi = ''
  # Loop through all fixations (by splitting the full datamatrix based on the dm.fixnr column)
  # and store the summarized info in summarydm
  for summaryrow, (fixnr, fixdm) in zip(summarydm, ops.split(dm.fixnr)):
      summaryrow.stime = fixdm.time[0]
      summaryrow.dur = fixdm.time[-1] - fixdm.time[0]
      summaryrow.x = fixdm.rawx.median
      summaryrow.y = fixdm.rawy.median
      summaryrow.psize = fixdm.psize.median
      summaryrow.fixnr = fixnr
      # Loop through all ROIs, and see if the x,y coordinates fall within the ROI boundaries
      for roi, coor in ROIS.items():
          if summaryrow.x >= coor['x1'] and summaryrow.x <= coor['x2'] \
                  and summaryrow.y >= coor['y1'] and summaryrow.y <= coor['y2']:
              summaryrow.roi = roi
  # Save the summary as a csv file
  io.writetxt(summarydm, OUTPUTFILE)




  Check out SigmundAI.eu for our OpenSesame AI assistant!

• AndreaP

  October 2016

  Dear Sebastiaan, many many thanks that was very useful! i do not have much experience with Python (yet) so I am still struggling with installing packages in the shell. Once I ll solve this I will try out the code above! Thank you again for your help!
• sebastiaan

  October 2016

  You could even run this from within OpenSesame, by putting the code in an inline_script, selecting it, and clicking the 'Run selected text' button at the top-right. Not necessarily the most convenient in the long run. But possible.



  Check out SigmundAI.eu for our OpenSesame AI assistant!

• IguaCat

  January 2018 edited January 2018

  Hi Sebastiaan, your script seems to be very helpful, thank you a lot for providing it...I'm trying to do this my self since days without success (not the greatest programmer...) Unfortunately, I only get the headers in the output file and I have no real clue what is going on I cannot attach one of my output tsv here because they are too big. I get no error message, only warnings:
  C:\Users\schischi\Anaconda3\lib\site-packages\datamatrix\py3compat.py:91: UserWarning: Some rows miss column rawx
  warnings.warn(safe_str(msg), *args)

  And this for every column...I would be grateful for any help or suggestions!
  Thank you,
  Cathi

  Edit: here is dropbox link to one of my file https://www.dropbox.com/sh/89hilbno4fayoej/AAA8M0MClTWeThobYHV85Pgja?dl=0
• IguaCat

  January 2018

  Sorry, I was just incredibly stupid...I tried nearly everything...and then I realized that I only had to change 'FALSE' in 'False'
• hanzh

  January 2018 edited January 2018

  Just came across with @sebastiaan 's code snippet. I found it to be very useful. My question is: I noticed that the fixation's coordinate and the pupil size were the median of samples - is this usually how EyeTribe data is handled? For now, I'm importing the raw gaze data to OGAMA (http://www.ogama.net/) just to detect the fixations and then export the event data, which is very inefficient...

  Thanks for your help!
• sebastiaan

  January 2018

  My question is: I noticed that the fixation's coordinate and the pupil size were the median of samples - is this usually how EyeTribe data is handled?

  There is no established standard for the EyeTribe per se, but a median is simply more robust to noise. So therefore I would use the median in these kinds of cases.

  I should also point out that I wrote a Python parser for EyeLink, EyeTribe, and SMI data files (it was originally only for the EyeLink, hence the name):

  • https://github.com/smathot/python-eyelinkparser

  It's not documented very well, and for the moment I don't intend to actively support it. But it's still easier than writing custom scripts.
